| Technical data |
|
| Output voltage at 1000 Hz, 5cm/sec. |
500 µV |
| Channel balance at 1 kHz |
1 dB |
| Channel separation at 1 kHz |
25 dB |
| Channel separation at 15 kHz |
18 dB |
| Frequency range at – 3dB |
20-40.000 Hz |
| Frequency response |
20-20.000 Hz ±1,5 dB |
| Tracking ability at 315Hz at recommended tracking force *) |
90 µm |
| Compliance, dynamic, lateral |
15 µm/mN |
| Stylus type |
Nude FG80, tapered aluminium cantilever |
| Stylus tip radius |
r/R 5/80 µm |
| Tracking force range |
2-2,5 g (20-25 mN) |
| Tracking force, recommended |
2,3 g (23 mN) |
| Tracking angle |
20° |
| Internal impedance, DC resistance |
6 Ohm |
| Recommended load impedance |
10-200 Ohm |
| Cartridge body material |
Grinded wood/Resin comp. |
| Cartridge colour |
Bronze |
| Cartridge weight |
10,5 g |
| *) Typical value |
|
